<< 点击显示目录 >> 主页  贝加莱轴控硬件使用助手 > 常用轴控设备说明 > ACOPOSmulti > 接线 > 8BVI 逆变器模块 > Single-axis modules (single- and double-width) - Pinout overview

Single-width

Image: 8BVI0014HxS0.000-1, 8BVI0028HxS0.000-1, 8BVI0055HxS0.000-1, 8BVI0110HxS0.000-1 - Pinout overview

Double-width

Image: 8BVI0220HxS0.000-1, 8BVI0330HxS0.000-1, 8BVI0440HxS0.000-1 - Pinout overview
